Workflows

Rules decide. Workflows do. EML has three kinds, and picking the right one is most of the work: a state machine for the lifecycle an object moves through, a hook workflow for side effects around a single write, and a saga for a process that touches several entities and carries values between steps.

State machines

Each state is a value of the entity's status column; each transition is a change the application will allow. Everything else is refused.

%%meta name: Lead Lifecycle
%%meta kind: workflow
%%workflow LeadLifecycle entity: Lead kind: state
stateDiagram-v2
    [*] --> new
    new          --> working      : engage
    working      --> nurturing    : nurture
    nurturing    --> working      : re_engage
    working      --> qualified    : qualify
    qualified    --> working      : return_to_working
    qualified    --> converted    : convert
    working      --> disqualified : disqualify
    nurturing    --> disqualified : disqualify
    new          --> disqualified : reject
    converted    --> [*]
    disqualified --> [*]

    %%rbac role:sales_rep|account_executive|sales_manager on Lead.update
    %%rbac role:sales_manager|sales_ops on Lead.convert
    %%rbac role:sales_manager on Lead.disqualify
    %%trigger webhook:marketing -> ingestInboundLead on Lead
    %%trigger cron:0 7 * * 1 -> recycleStaleLeads on Lead

%%rbac restricts a transition to roles. %%trigger declares what else can start one: cron:, webhook: or message:. Both are renderer-safe comments, so the diagram still draws as a plain state chart.

What the generator does with it

Each state machine becomes a workflow definition holding BPMN. On create the definition puts the new record into the machine's starting state — the [*] --> new edge, written to the entity's status column. On update it records a run without touching the state: the transitions constrain what an update may do, they are not a licence to rewind it. The full machine is stored in the definition's description, which is what the Workflow Designer displays.

Hook workflows

A flowchart of the process, plus %%hook directives binding named handlers to lifecycle events. The chart is for the reader; the directives are what the generator compiles.

%%meta name: Contact Hygiene
%%meta kind: workflow
%%workflow ContactHygiene entity: Contact kind: hook
flowchart TD
    A[Client Request] --> B[Validate Request]
    B --> C[beforeCreate: normalizeEmail]
    C --> D[customValidate: ensureUniqueEmail]
    D --> E[Process Contact]
    E --> F[afterCreate: enqueueWelcomeSequence]
    F --> G[afterUpdate: syncToMarketingPlatform]
    G --> H[beforeRead: enforceFieldLevelSecurity]
    H --> I[afterRead: maskPersonalData]
    I --> J[afterDelete: purgeMarketingConsent]
    J --> K[Response]

    %%hook beforeCreate normalizeEmail on Contact[field: email]
    %%hook customValidate ensureUniqueEmail on Contact[field: email]
    %%hook afterCreate enqueueWelcomeSequence on Contact
    %%hook afterUpdate syncToMarketingPlatform on Contact[field: email_opt_out]
    %%hook beforeRead enforceFieldLevelSecurity on Contact
    %%hook afterRead maskPersonalData on Contact[field: phone, field: mobile]
    %%hook afterDelete purgeMarketingConsent on Contact

The thirteen events

This is also the honest answer to "where does the code I still have to write live?". A minted account number, a welcome email, a masked phone number: the model says that it happens and when; you say how.

Sagas: multi-step processes

A saga is a flowchart whose edges give the running order and whose nodes are bound to executable steps by %%step. This is how one event reaches several tables.

%%workflow LeadConversion entity: Lead kind: saga trigger: rule
flowchart TD
    A([Lead qualified]) --> B{Size the account}
    B --> C[Open the account]
    C --> D[Create the primary contact]
    D --> E[Open the first opportunity]
    E --> F[Mark the lead converted]
    F --> G[Stamp the account tier]
    G --> H([Converted])

    %%step B Decision decisionTable: {"hitPolicy":"first","inputs":[{"id":"i1","field":"score"}],"outputs":[…],"rules":[…]}
    %%step C CreateEntity entity: Account as: newAccountId fields: {"name":"company_name","tier":"accountTier",…}
    %%step D CreateEntity entity: Contact as: newContactId fields: {"account_id":"newAccountId",…}
    %%step E CreateEntity entity: Opportunity as: newOpportunityId fields: {"account_id":"newAccountId","contact_id":"newContactId",…}
    %%step F UpdateEntity field: status value: converted
    %%step G UpdateEntity entity: Account targetSource: newAccountId field: tier source: accountTier

Steps share a context

This is the mechanism that makes a saga more than a list of writes. Every step can read the triggering record's columns plus anything an earlier step published:

• CreateEntity publishes the new row's id under as:.
• Formula publishes its result under target:.
• Decision publishes one variable per output column of the row that matched.
• A later step reads one by naming it in source: or targetSource:.

In the saga above, step B decides the tier, step C creates the account and binds its id as newAccountId, step D wires the contact to that exact account, and step G reaches back into the row step C created. Without the shared context a workflow could insert a row and never touch it again.

The step types

Two ways a saga starts

%%workflow LeadConversion   entity: Lead        kind: saga trigger: rule
%%workflow ClosedWonHandoff entity: Opportunity kind: saga trigger: automatic operation: UPDATE

trigger: rule runs only when a rule's trigger-workflow action names it, so the rule's condition decides. trigger: automatic runs on every write matching operation. Choose rule whenever the process should not fire on every save — an automatic workflow "gated" on a condition would run regardless of it.

The workflows in the CRM

Open one

A list of definitions proves the model was read. Opening one proves it was understood. This is LeadConversion — the saga written as a flowchart earlier in this chapter — as the running application renders it.
